BM 10-E COMPACT Drill

Description

Compact and powerful drill for fast, high-performance drilling in wood, aluminum, metal, and stainless steel Rated voltage min./max.: 220 / 240 VAC Rated voltage: 230 VAC Frequency min./max.: 50 / 60 Hz Protection class: Class II/protection insulation Input power: 600 W Output power: 360 W No-load speed min./max.: 0–2600 rpm Maximum rotational speed at rated load: 1676 rpm Maximum torque: 20 Nm Chuck mounting: 1/2" x 20 UNF Chuck capacity min./max.: 1–10 mm Clamping collar diameter: 43 mm Maximum drilling diameter in steel: 10 mm Maximum drilling diameter in aluminum: 10 mm Maximum drilling diameter in softwood: 25 mm Maximum drilling diameter in stainless steel: 8 mm Maximum thread tapping diameter: M6 Machine weight: 1.7 kg Cable length: 4 m Hand-delivery available in the Aveiro and Caldas da Rainha areas
